Cradle scTETRA 14.0 Patch 6

Free Download Cradle scTETRA 14 full version standalone offline installer for Windows it is a general-purpose CFD tool that uses Cartesian or cylindrical structured mesh to enable easy mesh generation and high-speed simulations to be performed in a fraction of the time.

You can also FREE download Cradle scSTREAM + HeatDesigner

Overview of Cradle scTETRA 14 Benefits

Due to the meshing nature and analysis system that enables large-scale calculation, scSTREAM works best at processing extensive simulations, where users are required to solve thermal problems of electronic devices and indoor environment, wind flow, and heat island phenomena.

To calculate heat transfer conditions depending on wiring patterns of a printed circuit board (PCB) in detail, the module can read Gerber data output from an electric CAD tool and import the data as a model for a thermo-fluid analysis. By using Gerber data, a more realistic calculation result can be obtained with the consideration of heat transfer affected by an uneven wiring pattern.

A flow generated by a moving rigid object can be calculated. Conditions including the motions of an object (translation, rotation, and elastic deformation), heat generation/absorption, and air supply/return can be set. The model of a moving object is created on another mesh. In this way, conditions such as the distance that the object moves are limited very little.

Overview of Cradle scTETRA 14 Features

• Modifying CAD data
• Mesh-adaptation analysis
• Discontinuous mesh
• Overset mesh
• Free surface (steady-state / transient)
• 6-degree-of-freedom motion (6DOF)
• Cavitation
• Fluid-structure interaction
• Compressible fluid
• Aerodynamic noise analysis
• Functions for turbomachinery

Technical Details and System Requirements

• Supported OS: Windows 10 / Windows 8.1 /Windows 7
• Processor: Multi core Intel Series or above, Xeon or AMD equivalent
• RAM: 4GB (8GB or more recommended)
• Free Hard Disk Space: 4GB or more recommended
